SLH-5G

Overview

Bornemann SLH Twin Screw Pumps are rotary positive displacement pumps, using two screws to convey the product along the screw axis. The contact free, intermeshing screws and the housing form closed chambers, constantly moving product from suction to discharge. Bornemann Pump Series SLH-5G provides safe and efficient operations for continuously increasing demands in hygienic environments. This allows Bornemann to offer you the ideal solution for every application.

Typical applications:

Beverages	Food	Dairy Products	Confectionary	Pharmaceutical
Juices Concentrates Syrups Wines Sparkling wines Malt Extract Wort Flavourings Fruit pulp	Oils & fats Soups Sauces & ketchup Dressings Mayonaise Dough & batter Meats Sausage meat Pet food Baby food Purees	Yoghurt Quark Cream Butter Desserts Concentrates Melted Cheese Cream Cheese Curds Spreads	Marmalade Jams Honey Chocolate Cream Fillings Fudge Molasses Sugar syrup Moussse	Chemicals Lotions Cosmetics Creams Gels Liquid soap Toothpaste











Features & Benefits

Convey & Clean with One Pump Only
Bornemann dual purpose SLH pumps combine advantages of a conventional positive displacement pump with the performances of a centrifugal pump. It conveys low and high viscous products and achieves the required flow velocity for cleaning.	This eliminates the need for a second pump and reduces valves, piping and controls.If the material being pumped requires manual cleaning, then the SLH-5G can be easily dismantled and cleaned in situ. Thus significantly reducing maintenance and product changeover times.
Product Integrity
The axial conveyance and the non-contact working principle protects the product and maintains its size, surface and visual integrity.	Sheer sensitive handling of the product are major advantages of the SLH operating principle
Operating Envelope
Different combinations of rotor diameter and pitch fit customer requirements.	Bornemann SLH pumps operate at a wide range of speed, providing flexibility for different operating points including CIP parameters.
Dry Running
Non-contact rotors and flushed seal configuration	Bornemann SLH is able to run dry for a defined period of time for increased system safety even at low tank levels
Long Service Life
Bornemann SLH pumps feature no metal-to-metal contact between rotors and housing	Trouble-free conveyance even for abrasive product and minimized downtime.
Low Pulsation
Bornemann Twin Screw pumps operate nearly pulsation-free	Avoiding vibration of piping systems and secure safe system layout, particularly for aseptic conditions.
Hygienic Design
State of the art hygienic design with contact-free operation of the rotor, no dead ends and self-draining design	Gguaranteeing sanitary and aseptic standards and protect production and product.



Specifications

SLH-5G Twin Screw Pump Performance Data

SLH-5G 5000

• Flow rate: 350 m³/h
• Differential pressure: up to 25 bar
• Max. temperature: 175°C

SLH-5G 4000

• Flow rate: 200 m³/h
• Differential pressure: up to 25 bar
• Max. temperature: 175°C

SLH-5G 3000

• Flow rate: 100 m³/h
• Differential pressure: up to 25 bar
• Max. temperature: 175°C

SLH-5G 2000

• Flow rate: 50 m³/h
• Differential pressure: up to 25 bar
• Max. temperature: 175°C

SLH-5G 1000

• Flow rate: 20 m³/h
• Differential pressure: up to 25 bar
• Max. temperature: 175°C

Connection options	Pump options	Seal Options
DIN 11851 dairy coupling DIN 11864-2 SMS 1146 DIN 32676 Open Suction	Hardening for abrasive products 1.4462/318LN Surface polishing to roughness <0.5 Heated pump casing Handle on pamp casing i-Alert for vibration monitoring	Single Seal Dual Seal Chocolate specific seal Knife-edge seal
